| Name: | PDC Drag Bit | Material: | Carbide |
|---|---|---|---|
| Structure: | Body With PDC Cutters | Size: | 60mm To 450mm |
| Use:: | Well Drilling , Coal Mine | Color: | Golden |
| Processing Type: | Casting | Model: | 4 Wing Drag Bits |
4 wings pdc bits
1. The bit is suitable for soft to medium soft formations.
2. Cutting structure is force balanced, bit blade is asymmetrically designed, and spiral blade and spiral gage
are also designed so that the load on bit is balanced that resulting better stability of the bit.
3. Multiple types of high performance PDC cutter are strategically arranged on the bit for improved
service life the bit.
4. Shock absorbers are designed to make the bit capable of drilling through formations with hard stringers.
5. Hydraulic system of the bit is optimized using dynamic flow pattern simulation technology to enhance
cleaning and cooling effects of the bit to effectively prevent bit from balling.
6. Erosion on bit surface is effectively prevented by utilizing hardfacing material of highly erosion resistant
and applying advanced base metal enhancement technology.
7. Ports on bit are also optimally designed to prevent erosion of water courses inside the bit.
Recommended drilling parameters of PDC diamond bit
| Bit size (inches) | Recommended drilling parameters | |||||
| Flow rate | Rotation speed(L/s) | Weight on bit(KN) | Specific Hydraulic Horsepower(HIS) | Makeup torque (kn.m) | ||
| 8 1/2 | 25-38 | 60-250 | 100-30 | 2-7 | 24-26.5 | |
| 8 3/4 | 25-38 | 60-250 | 100-30 | 2-7 | 24-26.5 | |
| 9 1/2 | 25-38 | 60-250 | 100-30 | 2-7 | 40-45 | |
| 12 1/4 | 44-60 | 60-250 | 150-30 | 2-7 | 50-60 | |
Application:
PDC bits are used for water well drilling, geotechnical and environmental drilling, mineral exploration, geothermal wells, geothermal drilling, construction and utility work
Standard size:56,65,75,94,113,133,153mm(2inch to 6inch)
Wings/Blade:3,4
Thread :as requested
Suitable for soft to medium hard rock formations(f=1-8),not available in broken,fractured,strong abrasive formations.
Feature:
High quality polycrystalline diamond compact (PDC) cutters as the cutting teeth, the bits have stable quality, high drilling efficiency, long service life.You can select different types of PDC bits according to the characteristics of formations,and improve the overall drilling efficiency.
