Product Details:
Payment & Shipping Terms:
|
| Model Number: | HH180 | Type: | Geological Drilling Machine |
|---|---|---|---|
| Power Type: | Diesel | Dimension(L*W*H): | 2400*800*140 |
| Usage: | Water Well | Drill Rod Dia.: | 42 - 60mm |
| High Light: | dth drilling machine,down the hole drill rig |
||
HH180 Geological Drilling Rig Machine Gold Mining Machine With Fully Hydraulic System
1. Fully hudraulic system, work with air compressor.
2. Drill fast in soft earth and in hard rock earth
3. Mainly used for water well drilling,earth sample taking, mining exploration, rock falling fence, Geological Drilling, etc,
4. Keeping bracket is installed on the hosit to form a double wheel support structure, able to withstand strong blow
5. Vertical box are fixed by four groups of bearings to ensure that the rotary machine has sufficient rigidity to overcome gravel layer and other complex geological conditions.
6. the machine is equipped with national patent technology---taper clutch, with charactristics of strong transmission troque, easy operation and free maintenance.
7. 53 x 59 drilling rod adopted, high rigidity and strong delivery torque.
| Model | HH130Y | HH180Y | HH200Y |
| Drilling Depth(m) | 130 | 180 | 200 |
| Open hole dia.(mm) | 220 | 220 | 325 |
| End hole dia.(mm) | 75 | 75 | 75 |
| Drill rod dia. | 42-60 | 42-60 | 42-60 |
| Drilling angle(°) | 90-75 | 90-75 | 90-75 |
| Matching power(kw) | 13.2 | 13.2 | 14.7 |
| Weight without power | 600/740 | 620/750 | 880/970 |
| Dimension(m) | 2.4*0.8*1.4 | 2.4*0.8*1.3 | 2.7*0.9*1.5 |
| Spindle Speed(r/min) | 142/285/570 |
130/300/480/730 /830/1045 |
64/128/287/557 |
| Spindle Stroke(mm) | 450 | 450 | 450 |
| Winch max. pull force(kg) | 2000 | 2100 | 2500 |
| Winch pull speed(m/s) | 0.41-1.64 | 0.35-2.23 | 0.12-0.95 |
| Winch rope dia.(mm) | Φ9.3 | Φ9.3 | Φ12.5 |
| Winch roll capacity(m) | 27 | 27 | 35 |
| Drill mast rated loat(ton) | 18 | 18 | 18 |
| Drill mast Height(m) | 6.5 | 6.5 | 6.5 |
| Mud pump flow(l/min) | 95 | 95 | 145 |
| Mud pump max. pressure(Mpa) | 1.2 | 1.2 | 2 |
| Mud pume times/min | 93 | 93 | 93 |
| Intel hos dia.(mm) | 51 | 51 | 51 |
| Outlet hose dia.(mm) | 32 | 32 | 38 |
