API Carbide PDC Water Well Drill Bits For Complex Formation

Large Image : API Carbide PDC Water Well Drill Bits For Complex Formation

Product Details:

Place of Origin:	China
Brand Name:	ShiTan
Certification:	ISO9001
Model Number:	130mm 140mm 220mm

Payment & Shipping Terms:

Minimum Order Quantity:	10/individual
Price:	Negotiation
Packaging Details:	Standard export package
Delivery Time:	Within 7-12 days
Payment Terms:	L/C, D/A, T/T, Western Union
Supply Ability:	20000pcs/Year

Contact Now

Detailed Product Description

Name:	PDC Drag Bit	Material:	Carbide
Use:	Coal Mining	Wing:	3 Wing,4 Wing
Certification:	API	Size:	130mm 140mm 220mm
Processing Type:	Mine Drilling Parts	PDC Cutter:	Flat / Dome
Machine Type:	Drilling Equipment
Highlight:	PDC Water Well Drill Bits , Complex Formation pdc drilling bit , API Water Well Drill Bits

API Carbide PDC Water Well Drill Bits For Complex Formation

Product Specifications

Attribute	Value
Name	PDC drag bit
Material	Carbide
Use	Coal Mining
Wing	3 wing, 4 wing
Certification	API
Size	130mm 140mm 220mm
Processing Type	Mine drilling parts
PDC Cutter	Flat / Dome
Machine Type	Drilling Equipment

High Adaptability PDC Water Well Drill Bit For Complex Formation

Key Features

Designed for drilling soft to medium formations with low drilling pressure, medium-low speed, and high drainage capacity
Ideal for non-coring drilling in formations including mudstone, limestone, shale, sandstone, and granite
Cost-effective solution with excellent performance in appropriate formations
Available in various configurations including coring/non-coring bits, sintering matrix bits, and anchoring bits
Widely used in geological exploration, coal mining, water conservancy, hydropower, and construction projects
Custom designs available for specific geological conditions and special strata requirements

PDC Cutter Selection Guide

Cutter Type	Characteristics	Recommended Formations
Sharp PDC Insert	Optimal for soft & medium rock. Provides faster drilling than flat cutters in these formations	Mudstone, shale, soft sand, peat, tuff, hard marl, sandy clay, limestone, marble, dolomite, rhyolite, limonite
Flat PDC Insert	Superior for medium & hard rock. Offers better wear resistance than sharp cutters in hard formations	Limestone, marble, dolomite, rhyolite, limonite, basalt, gneiss, granodiorite, hornfels, pegmatite, diabase
Spherical PDC Insert	Combines fast drilling with excellent wear resistance	Best choice for soft to medium hard rock formations
