Hydraulic Crawler Drilling Rig 200m Depth Diesel Water Well

Large Image : Hydraulic Crawler Drilling Rig 200m Depth Diesel Water Well

Product Details:

Place of Origin:	China
Brand Name:	ShiTan
Certification:	ISO9001
Model Number:	GK-200

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotiation
Packaging Details:	Standard Export package
Delivery Time:	Within 7-12 days
Payment Terms:	L/C,D/A,T/T,Western Union
Supply Ability:	2000set/year

Contact Now

Detailed Product Description

Type:	Hydraulic Crawler Drilling Rig	Engine:	Diesel Power
Dimension(LWH):	17308601360mm	Application:	Water Wells Drilling/Exploration
Drilling Depth:	200m	Color:	Orange / Yellow
Feature:	High Drilling Efficiency
Highlight:	Mobile Borehole Drilling Machine , geological drilling machine , Mobile Drilling Machine

Yellow Mobile Drilling Machine / Crawler Mounted Drill Rig For Water Well

Product Specifications

Type	Hydraulic crawler drilling rig
Engine	Diesel Power
Dimension (L×W×H)	1730 × 860 × 1360 mm
Application	Water Wells drilling/Exploration
Drilling depth	200m
Color	Orange / Yellow
Feature	High Drilling Efficiency

Product Overview

The GK-200 mobile drilling machine is a hydraulic feeding rig with large power, substantial lifting force (2T), and high transmission torque. This versatile equipment is designed for various demanding drilling applications.

Primary Applications

Engineering geological investigation for railways, hydropower, traffic, bridges, and dam foundations
Geological core drilling and physical prospecting
Small grout Confucius and drill hole drilling
Small well drilling operations

Technical Parameters

Drilling Rig Specifications

Drilling diameter (mm)	75, 91, 110, 130, 150, 300
Drilling depth (m)	200, 150, 100, 70, 50, 30
Drill pipe diameter (mm)	42, 50
Drilling angle (°)	90~75
Equipment size (L × B × H)	1730 × 860 × 1360 mm
Rig weight (except engine)	700 kg

Mobile Device

Moving length	350mm
Leave distance	300mm

Gyrator Specifications

Spindle speed (four gear) (r/min)	115, 230, 505, 1010
Spindle travel (mm)	450
Spindle no-load lifting maximum moving speed (m/s)	0.05
Spindle no load drop maximum movement speed (m/s)	0.067
Spindle maximum feed pressure (KN)	15
Spindle maximum lifting force (KN)	25
Spindle maximum output torque (KN•m)	1.5

Winch Assembly

Winch maximum lifting force (single rope)	20 KN
Reel speed (r/min)	20, 39, 85, 170
Reel circumferential speed (m/s)	0.172, 0.345, 0.738, 1.476
Reel diameter (mm)	140
Wire rope diameter (mm)	9.3
Wire rope density (m)	40
Brake diameter (mm)	278
Brake band width (mm)	50

Power Specifications

Oil pump type	YBC -20/125
Nominal pressure (Mpa)	12.5
Rated flow (ml/r)	20
Rated speed (r/min)	800-2500
Diesel engine	1115
Rated power (KW)	16.2
Rated speed (r/min)	2200
Motor type	Y160M - 4
Rated power (KW)	11
Rated speed (r/min)	1460
