XY-1 Horizontal Directional Drilling Machine For Geophysical Exploration

Mr. Zhu is worth to be trust, he has a good team, they provide us good service and reliable quality cable.

—— Aaron

Mr. Zhu provide us Water Well Drilling Rig with good price. thank you.

—— Julien

I'm Online Chat Now

XY-1 Horizontal Directional Drilling Machine For Geophysical Exploration

XY-1 Horizontal Directional Drilling Machine For Geophysical Exploration
XY-1 Horizontal Directional Drilling Machine For Geophysical Exploration

Large Image :  XY-1 Horizontal Directional Drilling Machine For Geophysical Exploration

Product Details:
Place of Origin: China
Brand Name: ShiTan
Certification: ISO9001
Model Number: XY-1
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Delivery Time: Within 7-12 days
Payment Terms: L/C, D/A, T/T, Western Union
Detailed Product Description
Type: Horizontal Water Well Drilling Voltage:: 220V / 380V
Model Number: XY-1 Usage: Water Well,railways
Dimension(L*W*H): 1710*860*1360 Color: Customer Required
High Light:

horizontal drilling rig

,

horizontal water well drilling

XY-1 Horizontal Directional Drilling Machine For Geophysical Exploration

Features

XY-1 horizontal directional drilling rig, which has compact structure and attractive appearance, adopts various advanced technologies and the proprietary technologies of the company, and its main peformance parameters and control technologies have reached the world advanced level. The main coponents of hydraulic system, electrical system and transmission system are of top-grade domestic & international brand with high reliability.
• Dual speed power head: drilling and pulling at low speed ensure smooth operation; The power head can slide at faster speed to reduce the auxiliary time and improve work efficiency during the assembly/disassembly of drilling stem with empty load.
• Rubber track: the rubber track has minor influence on the road, lawn, and scenic spot.
• Float clamp: the patented float clamp can effectively extend the service life of the drilling shaft.
• Automatic assembly/disassembly: the drill stem can be mounted and dismounted automatically, which improves the work efficiency, reduces the work intensity and thus reduces the number of work staff.
• Automatic anchoring: through hydraulic pressure drive, the cylinder and low speed large torque motor controls the push/pull of the drill stem, and it’s simple and convenient to operate.
• Rotatable control panel: it widens the field of view and reduces operator fatigue.
• Simple to operate: the rotation and push/pull of the power head is controlled separately, and it’s simple and convenient to operate. The operator can master the operation skills through short-time training.



Application and scope

1.1.1 It is suitable for drilling in reconnaissance, geophysical exploration, road and building exploration, blasting holes and other drilling engineering.
1.1.2 Alloy, steel grit and steel drop bits can be chosen according to the different stratas.
1.1.3 It can drill 2-9 grade sand clay and rock layer.
1.1.4 The rated drill depth shall be 100 meters and the deepest shall not exceed 120m.
1.2 Features
1.2.1 The oil pressure feeding mechanism can improve drilling efficiency and reduce the labor intensity.
1.2.2 A ball mounted card blessing mechanism replaces the chuck which can carry out without stopping the lever, easy to operate, safe and reliable.
1.2.3 Hole pressure gauge indicates pressure which can be easy to grasp the situation inside the hole.
1.2.4 Handle concentration, easy operation.
1.2.5 It is compact.The drill, water pump and diesel engine are installed on the same base, which occupies a small area.
1.2.6 It is light in weight, strong in decomposition and easy to remove .And it can be used in plains and mountains.


Drilling Rig
Drilling diameter(mm)75,100
Drilling depth (m)100
Drill pipe diameter (mm)42
Drilling angle(°)90-75
Equipment size(L * B * H)1640 * 1030 * 1440 (mm)
Rig weight (except engine)500
Gyrator
Spindle speed (four gear) (r/min)142,285,570
Spindle travel(mm)450
Spindle no-load lifting maximum moving speed(m/s)0.05
Spindle no load drop maximum movement speed(m/s)0.067
Spindle maximum feed pressure(KN)15
Spindle maximum lifting force(KN)25
Spindle maximum output torque(KN• m)0.5
Winch assembly
Winch maximum lifting force (single rope)10
Reel speed (r/min)55,110,220
Reel circumferential speed(m/s)0.42,0.84,1.68
Reel diameter(mm)145
Wire rope diameter(mm)9.3
Wire rope density (m)27
Brake diameter(mm)230
Brake band width (mm)50
Water pump
Pump typeHorizontal single cylinder double acting
Maximum displacement (motor)(L/min)95 (77)
The maximum allowable pressure (Mpa)1.2
Work pressure (Mpa)0.7
Cylinder diameter (mm)80
Piston stroke(mm)100
Oil pump
Oil pump typeYBC -20/125
Nominal pressure (Mpa)12.5
Rated flow(ml/r)20
Rated speed(r/min)800-2500
Diesel engine or motor
Diesel engineZS 1100
Rated power (KW)16.2
Rated speed (r/min)2200
Rated pressure(Mpa)12.5
Motor typeY160 - 4
Rated power (KW)11
Rated speed (r/min)1460
