Hot Sale API 2 3/8'' REG Standard 76 89 102 Mm Water Well Rock Dth Drill Rod

Mr. Zhu is worth to be trust, he has a good team, they provide us good service and reliable quality cable.

—— Aaron

Mr. Zhu provide us Water Well Drilling Rig with good price. thank you.

—— Julien

I'm Online Chat Now

Hot Sale API 2 3/8'' REG Standard 76 89 102 Mm Water Well Rock Dth Drill Rod

Hot Sale API 2 3/8'' REG Standard 76 89 102 Mm Water Well Rock Dth Drill Rod
Hot Sale API 2 3/8'' REG Standard 76 89 102 Mm Water Well Rock Dth Drill Rod
video play

Large Image :  Hot Sale API 2 3/8'' REG Standard 76 89 102 Mm Water Well Rock Dth Drill Rod

Product Details:
Place of Origin: China
Brand Name: ShiTan
Certification: ISO9001
Model Number: 79.89.102.114
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Standard export package
Delivery Time: Within 7-12 days
Payment Terms: L/C, D/A, T/T, Western Union
Detailed Product Description
Product Name: Hollow Steel Drilling Rod Processing Type: Forging
Machine Type: Drilling Equipment, Drilling Tool Diameter: 60mm-150mm
Application: Stone Drilling, Coal Mining,Quarry Use: Coal Mining
Usage: Drilling And Construction Length: 400mm-8000mm
Highlight:

integral drill rods

,

mining drill rods

Hot Sale API 2 3/8'' REG Standard 76 89 102 Mm Water Well Rock Dth Drill Rod





Product Description

DTH drill pipes are widely used in mines, water wells, geothermal, petroleum and other types of DTH rigs. High quality carbon steel ensures the close combination of friction welding process and joint.according to different application, different diameters of drill tubes are needed, basically, smaller dth hammers need smaller dth drill tubes, vice versa. usually we are offering 50mm, 60mm, 76mm, 89mm, 95mm, 102mm, 114mm, 127mm, 140mm, 159mm.If you have special requirements, please contact us. We have professional and experienced engineers who understand that some drilling conditions may require special bit configuration. We can design and manufacture according to your specific requirements.


Specifications of drill pipe:



Product name Friction welding drill pipe
Diameter 50-159mm
Length 1000mm to 6000mm
Wall thickness 5.5/6.5mm/7.5/8.5mm/10mm
Material High manganese steel
Thread API REG
Application Well-drilling,coal drilling,quarrying
Advantage High performance and high pressure



Advanced product system


DTH drill pipes play a significant role in all DTH drilling, regardless type of rock, hole depth or drill rig.DTH drill pipe is
mainly used in the drilling blasting hole, guardrail hole, mountain reinfrcement, anchoring and other engineering holes in
mines,quarris, high ways, railways and so on.



Feature:


1.Pipe body : cold draw seamless pipe . so the pipe have the accurate size , good centralizer.
2.Thread connector :Heat and Nitrogen treatment , so the pipe is more durable and easier to load and unload .
3.Friction welding .

1: OD: 89mm ( 3.5'' inch) thread drill pipe
2: Connection: 121mm
3: Material:R780/E75/N80
4: Thread: NC38
5: Wall thickness:9.5mm/10mm
6: Yield/Tensile strength: Min 517Mpa/Min 689Mpa
7: Suitable for water well, geothermal well, gas well
8: Safe drilling depth: Within 1,500 meters
9: Tool joint:35CrMo/40Cr
10: Length: 4.5meters or as your requirement



Advantages of friction welding drill pipe:



1) The optimal combination of drill pipe is realized, the rod body and joint can be made of different materials, and the heat treatment optimization performance is improved.Other forms of drill pipe cannot be achieved.

2) The joint has high mechanical properties and abrasion resistance.Longer service life than other types of drill pipe.

3) Light weight and good flexibility.

4) The drilling fluid channel inside the drill pipe can be designed.The design of the inner hole channel of the threaded probe can fully consider to reduce the hydraulic loss when passing, especially to reduce the loss caused by the threaded joint part, can improve the working efficiency of the drilling fluid system.

5) With the improvement of welding equipment, welding process and technology and the improvement of heat treatment technology, the connection strength of friction welding is higher than that of the base material itself.The welding strength of the weld is higher than that of the base material.

6) Conduct integral tempering and heat treatment on the pier of friction welding drill pipe after it is thick, and its bending resistance and flexibility are greatly improved.



Hot Sale API 2 3/8'' REG Standard 76 89 102 Mm Water Well Rock Dth Drill Rod 0Hot Sale API 2 3/8'' REG Standard 76 89 102 Mm Water Well Rock Dth Drill Rod 1Hot Sale API 2 3/8'' REG Standard 76 89 102 Mm Water Well Rock Dth Drill Rod 2







Hot Sale API 2 3/8'' REG Standard 76 89 102 Mm Water Well Rock Dth Drill Rod 3Hot Sale API 2 3/8'' REG Standard 76 89 102 Mm Water Well Rock Dth Drill Rod 4
