XY-2B 500 Meters Depth Crawler Mounted Hydraulic Water Well Drilling Rig

Mr. Zhu is worth to be trust, he has a good team, they provide us good service and reliable quality cable.

—— Aaron

Mr. Zhu provide us Water Well Drilling Rig with good price. thank you.

—— Julien

I'm Online Chat Now

XY-2B 500 Meters Depth Crawler Mounted Hydraulic Water Well Drilling Rig

XY-2B 500 Meters Depth Crawler Mounted Hydraulic Water Well Drilling Rig
XY-2B 500 Meters Depth Crawler Mounted Hydraulic Water Well Drilling Rig XY-2B 500 Meters Depth Crawler Mounted Hydraulic Water Well Drilling Rig

Large Image :  XY-2B 500 Meters Depth Crawler Mounted Hydraulic Water Well Drilling Rig

Product Details:
Place of Origin: China
Brand Name: ShiTan
Certification: ISO9001
Model Number: XY-2B
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: export packing
Delivery Time: Within 7-12 days
Payment Terms: L/C, D/A, T/T, Western Union
Detailed Product Description
Features: Rapid Migration Type: XY-2B Crawler Mounted Hydraulic Water Well Drilling Rig
Model Number: XY-2B Voltage: 240V
Power Type: Diesel Dimension(L*W*H): 2150*900*1690 Mm
Appliacation: Engineering Geological Drilling Depth: 500 Meters
Drilling Hole Diameter: 300 Mm Color: Yellow ,Red,Blue
High Light:

horizontal drilling machine

,

horizontal water well drilling

XY-2B Crawler Mounted Hydraulic Water Well Drilling Rig





Product Description



XY-2B water well drilling rig is a lightweight, efficient and multifunctional drilling equipment, The water well drilling rig is mainly applicable to industrial and civil drilling, geothermal drilling, has the advantages of compact structure, fast advancing, mobile

and flexible wide application region etc.. Pneumatic well drill is especially suitable for water intake in mountainous and rocky
strata.



Product Specifications:



Drilling capacity (m) Φ73 rod 100
Φ60 rod 320
Φ50 rod 380
Φ42 rod 530

Spindle speed(r/min)
Forward 57;99;157;217;270;470;742;1024
Reverse 45;212

Max torque(Nm)
2760

Drilling angle renge
0-90°

Spindle max pull force(KN)
60

Spindle stroke (mm)
600

Hoist max lift capacity with single rope (KN)
30

Spindle inner dia (mm)
76

Oil pump
SCB32/12

Power unit

Electric motor
Y180L-4,22Kw

Diesel engine
395K2,19.85Kw

Overal dimension (mm)
2150×900×1690

Drill weight(excluding power)(kg)
950



Product Features



Electric motor or diesel type hydraulic horizontal directional drilling machine

1. Hydraulic feeding drill rig for soil test and SPT equipment .

2.Engineering geological survey, hydrology, water wells,sky buildings,dams,harbors

bridge,oil exploration,etc

4.Power ,flexible and easy manitenance.

5.Small and light weighted core drill
6. Electric motor or diesel type hydraulic horizontal directional drilling machine



Applications:



XY-2B hydraulic feed core drill is small and light weighted, mainly used in shallow and medium deep diamond tungsten carbide core drilling, can also be used in engineering geological, hydro-geological, water well and pile grouting hole drilling. It is equipped with two-wheel trailor, in order to move easily.



How deep can you drill your own well?



Drilling a Water Well for household use will usually range from about 100 feet to 500 feet deep, but... When drilling a new well for your home or business, the depth of the well depends on the geology and underground water levels of the area

What problems should be paid attention to when operating crawler type water well drilling rig



XY-2B 500 Meters Depth Crawler Mounted Hydraulic Water Well Drilling Rig 0XY-2B 500 Meters Depth Crawler Mounted Hydraulic Water Well Drilling Rig 1

XY-2B 500 Meters Depth Crawler Mounted Hydraulic Water Well Drilling Rig 2XY-2B 500 Meters Depth Crawler Mounted Hydraulic Water Well Drilling Rig 3XY-2B 500 Meters Depth Crawler Mounted Hydraulic Water Well Drilling Rig 4
