Professional Low Pressure Drilling Mud Pump For Geological Investigation Purpose
Key Attributes
| Structure |
Piston Pump |
| Power |
Electric |
| Fuel |
Diesel |
| Pressure |
Low Pressure |
Product Overview
The BW drilling mud pump is a horizontal, triplex, single-acting reciprocating piston pump designed for geological investigation purposes. This reliable and versatile pump can be powered by diesel engine, electric motor, or hydraulic motor, offering flexible operation options.
Key Features
Compact structure with smooth operation
Large-scale variable flow rates with high output pressures
Extended service life for wearing parts
Steady performance with excellent intensity and rigidity
Abundant standard and interchangeable parts
Simple operation with close-range or long-distance control capability
Technical Specifications
| Cylinder Liner Diameter (mm) |
150 |
| Piston Stroke (mm) |
180 |
| Theoretical Flow Rate (L/min) |
600-850 |
| Rated Pressure (MPa) |
2-3 |
| Strokes Per Minute |
58-82 |
| Suction Pipe ID (mm) |
127 |
| Discharge Pipe ID (mm) |
64 |
| Input Rotating Speed (r/min) |
470 |
| Input Power (kW) |
40 |
| Dimensions (L×W×H) (mm) |
2000×1030×1400 |
| Weight (kg) |
1500 |
Jinzhou Shitan Machinery Equipment Co., Ltd. Main Products：
Pneumatic Drilling Rig / Air Drilling Rig（ST-180,ST-200,ST-260,ST-300,ST-350,ST-400,ST450,ST-450,ST-500, ST-600,ST-800 and other Pneumatic water well drilling Rigs.）, Crawler Water Well Drilling Rig / Trailer Mounted Drilling Rig / Water Well Drilling Rig / Hydraulic Borewell Machine / Hard Rock Drilling Equipment / Diamond Core Drill Rig / Geological Drilling Rig / Soil Testing Drilling Rig / Portable Water Well Drilling Rig（ST-30，ST-50，XY-1A, XY-1B, XY-2, XY-2B,GK180, GK200, GY150, GY200 and 30 impact drill rig,ZLJ series tunnel drilling rig and other geological drilling machines）Crawler Track Undercarriage, Drilling Mud Pump（BW150,BW160,BW200,BW250,BW850 series Drilling mud pumps）, Drilling Air Compressor, Water Well Drill Bits（PDC Drill Bit， Tricone Bit， DTH Button Bit）, Water Well Drill Pipe, Drilling Rig Spare Parts( drilling rods , drilling rods joint , casing pipe, casing coupling, core tube, core tube coupling, lifters, automatic drop hammer, sampler, SPT tool, wrench fork, pad fork, lock joint), Track Transporter
Good quality, professional after-sales service, welcome to order
