59mm Diamond Drilling 3 Wing Pdc Core Bit

59mm Diamond Drilling 3 Wing Pdc Core Bit

Large Image :  59mm Diamond Drilling 3 Wing Pdc Core Bit

Product Details:
Place of Origin: China
Brand Name: ShiTan
Certification: ISO9001
Model Number: 59-152mm
Payment & Shipping Terms:
Minimum Order Quantity: 10/individual
Price: Negotiation
Packaging Details: Standard export package
Delivery Time: Within 7-12 days
Payment Terms: L/C, D/A, T/T, Western Union
Supply Ability: 20000pcs/Year
Detailed Product Description
Name: PDC Drag Bit Material: Carbide
Use: Coal Mining Wing: 3 Wing,4 Wing
Certification: API Size: 59-152
Processing Type: Mine Drilling Parts PDC Cutter: Flat / Dome
Machine Type: Drilling Equipment
Highlight:

3 wing pdc core bit

,

Diamond Drilling pdc core bit

,

59mm pdc core bit

59mm Diamond Drilling 3 Wing PDC Core Bit
Product Specifications
Attribute Value
Name PDC drag bit
Material Carbide
Primary Use Coal Mining
Wing Configuration 3 wing, 4 wing
Certification API
Size Range 59-152 mm
Processing Type Mine drilling parts
PDC Cutter Type Flat / Dome
Machine Compatibility Drilling Equipment
Professional Water Well Diamond PDC Core Drilling Bit
Our PDC drill bits are engineered for optimal performance in water well drilling and mining exploration applications. These full face bits deliver exceptional penetration rates and extended service life across a wide range of rock formations.
Key Features
  • Superior performance in mining, civil engineering, and oil/gas applications
  • Available in multiple wing configurations (3-wing, 4-wing, 5-wing non-coring bits)
  • High-quality carbide construction with PDC cutters
  • API certified for quality assurance
Available Sizes
59mm, 65mm, 75mm, 76mm, 90mm, 94mm, 99mm, 101mm, 113mm, 114mm, 120mm, 123mm, 126mm, 127mm, 133mm, 143mm, 152mm,
2 1/4", 2 3/8", 2 7/8", 3", 3 1/2", 3 7/8", 4 3/4", 4 3/8", 4 7/8", 5", 5 1/2", 5 1/4", 5 1/8", 5 5/8", 6", 6 3/4"
Maintenance Guidelines
The PDC cutting teeth are the most critical component of our diamond compact bits. These polycrystalline diamond composite elements are sintered under extreme high temperature and pressure conditions, resulting in exceptional hardness but requiring careful handling.
Important Usage Recommendations:
  • Handle with care during packaging, transportation, and installation
  • Select appropriate bit type for specific geological conditions (soft, medium, or hard rock strata)
  • Always perform initial low-speed run-in (minimum 30 minutes)
  • Reduce rotation speed and axial pressure in complex geological environments
  • Proper axial pressure management prevents bit fracture
Our decade of experience in diamond compact bit development ensures optimal performance when these guidelines are followed.
