Product Details:
Payment & Shipping Terms:
|
| Type: | OEM Customized Portable 50 Meters Hydraulic Core Drilling Machine Core Drill Rig | Power Type: | Diesel |
|---|---|---|---|
| Weight:: | 480kg | Usage: | Water Well,railways, Core Drilling |
| Drilling Depth: | 50m | Dimension(L*W*H): | 1180×680×1600mm |
| Drill Pipe Diameter: | 42mm | Condition: | New |
| Weight: | 200KG | Hole Size Diameter: | 73-108mm |
| High Light: | 200m depths portable hydraulic drilling machine,200mm dia portable hydraulic drilling machine,oem portable hydraulic drilling machine |
||
GK200 Core Drill Rig is suitable for drilling wells, general exploration, geophysical prospecting, road and construction exploration, and blasting holes.According to the different layers of the bottom selection of alloys, diamonds and composite drill bits for drilling.It can drill 2-9 grades of sandy clay and rock formations.
GK 200 Meters Hydraulic Portable Core Drilling Rig Machine parameters:
| Drilling Rig | |
| Drilling diameter(mm) | 75,91,110,130,150,300 |
| Drilling depth (m) | 200,150,100,70,50,30 |
| Drill pipe diameter (mm) | 42,50 |
| Drilling angle(°) | 90~75 |
| Equipment size(L * B * H) | 1730 * 860 * 1360 (mm) |
| Rig weight (except engine) | 700 |
| Gyrator | |
| Spindle speed (four gear) (r/min) | 115,230,505,1010 |
| Spindle travel(mm) | 450 |
| Spindle no-load lifting maximum moving speed(m/s) | 0.05 |
| Spindle no load drop maximum movement speed(m/s) | 0.067 |
| Spindle maximum feed pressure(KN) | 15 |
| Spindle maximum lifting force(KN) | 25 |
| Spindle maximum output torque(KN• m) | 1.5 |
GK 200 Meters Hydraulic Core Drilling Machine Core Drill Rig Features
Drilling Rig Machine is applicable to small and medium-sized mines and road construction, defense and water conservancy and stone works in the large diameter borehole drilling operations.The energy losss does not increase with the drilling rod increasing
GK 200 Hydraulic Core Drill Rig Frequent Questions
Q1: Will you provide some spare parts of the machines?
Yes, of course.
Q2: What about the voltage of products? Can they be customized?
Yes, of course. The voltage can be customized according to your requirement.
Q3: Which payment term can you accept?
30% T/T deposit, 70% T/T before shippment
Q4: How long will you take to arrange production?
380V 50HZ we can delivery, the goods within 7-15 days.
Other electricity or other color we will delivery within 25-30 days.
Q5: Can you accept OEM orders?
Yes, with professional design team, OEM orders are highly welcomed.
