Triplex Plunger Piston Pump BW250 for Grouting Pump
BW250 Mud Pumps Usage:
Suitable for pumping and discharging sewage containing sediment and coal powder underground in coal mines, as well as for cleaning small wells in underground water tanks, pump rooms, and sewage ditches. Can be used as a delivery pump, pressure pump, and quantitative pump. Suitable for the extraction and transportation of coal slurry (containing a certain amount of solid particles) in mine water tanks and sedimentation tanks. Four sets of Chinese Pinyin letter combinations and numbers represent parameters such as pump model, pump form, flow rate, pressure, and matching power. The mortar pump can be used for grouting holes in prefabricated or cast-in-place components in the construction of buildings using prestressed technology. In ordinary construction projects, it can be used for bridges, culverts, mines, tunnels, etc
BW250 Mud Pumps Product Parameter:
| BW Mud Pump | ||||
| Model | BW150 | BW160 | BW250 | BW320 |
| Max. Flow Rate | 150L/min | 160L/min | 250L/min | 320L/min |
| Max. pressure | 7Mpa | 10Mpa | 6Mpa | 8Mpa |
| Power | 7.5kw | 11kw | 15kw | 30kw |
| Inlet pipe diameter | 51mm | 51mm | 76mm | 76mm |
| Outlet pipe diameter | 32mm | 32mm | 51mm | 51mm |
| Weight | 560kg | 480kg | 760kg | 1000kg |
BW250 Mud Pumps Features:
1. BW series mud pump is horizontal triplex grout pump with high stability and high pressure.
2. Eight gear shift to adjust the flow, large output capacity, simple operation.
3. High quality pump parts, less wearing parts, long service life, low construction cost.
4. Fast suction-discharge speed, high pump efficiency.
5. Less noise and dust, environmental operation.
BW250 Mud Pumps Application:
1. BW series mud pump is widely used for cement grouting and mud jacking in engineering construction.
2. BW mud pump can be used to grout borehole flushing fluids (mud, clean water, saponification liquid) or equipped with minor-caliber diamond drilling machine.
3. BW mud pump is widely used in railway, hydraulic engineering, metallurgical engineering, building construction, geological exploration, engineering exploration (within 1000m of the drilling depth) etc.
