200 Meters Depth Geological Drilling Rig Machine
Customized 200 Meters Depth Geological Drilling Rig Machine
It is widely utilized and featured in high power and hoisting load(2T), large torque transmission, etc. The rotating speed of vertical hexagonal spindle varies between 71r/min-825r/min. It is suited for the geotectonic survey, geological core drilling, small hole drillings for grout, blast and water well in railway, water coservancy, bridge, dam foundation and other constructions. Diamond drill vit, alloy drill bit and steel roller drill bit are available for drilling according to different geological structures.
Customized 200 Meters Depth Geological Drilling Rig Machine Parameter
| Drilling Depth |
200m |
| Application |
Geological core drilling |
| Drilling hole diameter |
75-300mm |
| End hole diameter |
75mm |
| Active drill rod |
53/59*4200mm |
| Rod diameter |
50,60mm |
| Drill angle |
90°-75° |
| Matched power(diesel power) |
15kw/2200r/min |
| Dimension |
2800*950*1700mm
|
Customized 200 Meters Depth Geological Drilling Rig Machine Characteristic
It has oil pressure feeding mechanism to improve drilling efficiency,
The rotary torque is large and the hole diameter is large.
Large active drill pipe and double guide rod are adopted to increase stability.
The drilling rig is equipped with upper ball clip type holding mechanism and hexagonal active drill pipe,
It is equipped with a pressure gauge at the bottom of the hole to indicate the pressure, so as to grasp the situation in the hole.
The handle is centralized and easy to operate.
The drilling rig is compact in structure, small in volume and light in weight.
Customized 200 Meters Depth Geological Drilling Rig Machine Advantage
· More Than 15 Years Experiences in DRILLING
· 100% Brand New Machines
· No MOQ,1Sets Ok,Small Order Welcome.
· Do The Drill Rigs As You Like !
· After Sales Service In 24/7
